PLAN: PROPOSED BRICK RESIDENCE FOR A. J. PRIESTMAN, LOT 76, EXCELSIOR STREET

1951
Overview

Plan for the Proposed Brick Residence for A. J. Priestman at Lot 76, Excelsior Street, showing front and side elevations, floor plan, lounge fireplace, and lot in relation to Excelsior Street.

The plan is dark blue in colour and a copy of the original with some details filled in by hand.

'9'6''' handwritten next to 'SECTION A - A' indicating height between ground level and eves of the building.

'7'6''' handwritten next to 'SIDE ELEVATION' indicating height between ground level and eves of the building.

'A J. Priestman' handwritten in black ink in bottom right corner under 'PROPOSED BRICK RESIDENCE for'.

Reverse:

Purple 'PLAN APPROVED' ink stamp, signed and dated '21/12/51'.

Purple 'SUBIACO MUNICIPALITY' ink stamp, filled in, signed and dated by hand in blue ink and pencil:

Ward: South

Street: Excelsior (handwritten in pencil)

Lot: 76

Sub-lot: 303

Date: 21/12/51

Signed in blue ink.

Purple ink stamp 'SUBIACO MUNICIPALITY, THIS PLAN IS ISSUED SUBJECT TO THE APPROVAL OF THE STATE HOUSING COMMISSION'

Purple ink stamp 'BEFORE WORK IS COMMENCED PLAN MUST BE SUBMITTED TO MET. WATER SUPPLY DEPT.'

A 'NOTICE TO BUILDERS', printed in red lettering, has been stuck to the back of the document.

Handwritten notes made in blue ink can be seen beside 'PLAN APPROVED' ink stamp.

Historical information

Found in TG during 2023 renovations.

Details

Details

Registration number
cwa-org-43-2023.426
Item type
Documents
Material
Paper
Ink
Width
480 mm
Height or length
375 mm
Keywords
Architecture
BUILDINGS
Excelsior Street
PRIESTMAN, A. J
Decade - 1950s
Year
1951
Last modified
Thursday, 17 July, 2025
Completeness
94
