PLAN: 'WORKERS HOMES BOARD BRICK HOUSE, W.H.T. TYPE 58A', FOR LOT 419 LUTH AVE, DAGLISH 1945

Black ink plan drawing on beige paper. The plan includes a Front Elevation, Plan, Section, and two side elevations.

At the bottom is the sizes of the rooms. They are listed as Main Building 1069 SQ FT (Square Feet), Front Porch 55, Back Verandah 196 and Laundry & WC (Water Closet/Toilet) 102.

The second box includes the architects initials: 'Drawn By J.H, Traced by JH'. It is dated 11.9.45

The title at the bottom reads: 'Workers Homes Board Brick House W.H.T Type 58A'.

The scale is 8'(feet) to 1 inch.

The plan has been stamped with a blue 'Subiaco Municipality' stamp and in red there is written:

Ward 'North' Lot '419'

Street 'Luth Ave' Sub-Lot 'Daglish'

Signed and dated 23/4/47
